Black Steel Pipe For Hydraulics

Product Description

This product is manufactured in compliance with several international standards for hydraulic pipes, ensuring quality and consistency:

EN 10305: European standard for precision steel tubes.
DIN 2391: German standard for seamless steel tubes used in hydraulic applications.

Product Advantages

Dimension

Cold Drawn/Rolled Seamless Precision Steel Tubes Confirming To DIN2391;EN10305-1;EN10305-4

OD	Thickness（mm）
mm	Thickness（mm）
6	6*1	6*1.5
8	8*1	8*1.5	8*2
10	10*1	10*1.5	10*2
12	12*1	12*1.5	12*2	12*2.5
14	14*1	14*1.5	14*2	14*2.5	14*3
15	15*1	15*1.5	15*2	15*2.5	15*3
16	16*1	16*1.5	16*2	16*2.5	16*3
18		18*1.5	18*2	18*2.5	18*3	18*3.5	18*4
20		20*1.5	20*2	20*2.5	20*3	20*3.5	20*4
22		22*1.5	22*2	22*2.5	22*3	22*3.5	22*4
25			25*2	25*2.5	25*3	25*3.5	25*4
28			28*2	28*2.5	28*3	28*3.5	28*4
30			30*2	30*2.5	30*3	30*3.5	30*4	30*4.5	30*5
32			32*2	32*2.5	32*3	32*3.5	32*4	32*4.5	32*5
34			34*2	34*2.5	34*3	34*3.5	34*4	34*4.5	34*5	34*6
35			35*2	35*2.5	35*3	35*3.5	35*4	35*4.5	35*5	35*6
38			38*2	38*2.5	38*3	38*3.5	38*4	38*4.5	38*5	38*6
40				40*2.5	40*3	40*3.5	40*4	40*4.5	40*5	40*6
42				42*2.5	42*3	42*3.5	42*4	42*4.5	42*5	42*6
45				45*2.5	45*3	45*3.5	45*4	45*4.5	45*5	45*6
46				46*2.5	46*3	46*3.5	46*4	46*4.5	46*5	46*6
48				48*2.5	48*3	48*3.5	48*4	48*4.5	48*5	48*6
50				50*2.5	50*3	50*3.5	50*4	50*4.5	50*5	50*6
54					54*3	54*3.5	54*4	54*4.5	54*5	54*6
60					60*3	60*3.5	60*4	60*4.5	60*5	60*6	60*8
Note: 1. We can produce other specification as your requirements. 2. Surface treatment: Bright, galvanized (yellow, white, colorful), phosphated，army green passivation.

Features

- - Corrosion Resistance: The black oxide coating offers excellent protection against corrosion, ensuring the pipes last longer, especially in harsh environments.
  - Durability: The carbon steel material provides high strength and long-lasting durability even under high-pressure conditions.
  - High Precision: The seamless manufacturing and cold drawing process ensures precise dimensions and smooth inner and outer surfaces.
  - Versatility: These pipes are designed to be used in a wide range of hydraulic systems and applications, offering a reliable and efficient solution.

Specifications

Specification	Details
Material	Carbon Steel (commonly ST37.4,E235)
Standard	EN 10305, DIN 2391, ASTM A179, etc.
Surface Treatment	Black oxide finish (corrosion-resistant)
Outer Diameter (OD)	4 mm to 120 mm
Wall Thickness (WT)	0.5 mm to 10 mm
Length	Customizable (Standard: 6 meters)
Surface Finish	Black steel finish with corrosion protection

Manufacturing Process

Material Preparation: The raw material is typically a high-quality carbon steel, such as ST37.4 E235, chosen for its strength and durability.
Seamless Pipe Formation: The pipe is produced using a seamless process, which eliminates welding and ensures uniform strength across the entire pipe.
Cold Drawing: The pipe undergoes cold drawing to achieve high precision in size and smooth surface finish.
Black Oxide Coating: The steel pipe is coated with a black oxide finish to provide excellent corrosion resistance and prevent rust.
Heat Treatment: Depending on the requirements, the pipes may undergo heat treatment (annealing) to enhance mechanical properties and relieve internal stresses.
Inspection & Testing: Each pipe is subjected to rigorous quality control tests to ensure compliance with required standards. These tests include dimensional checks, pressure tests, and surface quality evaluations.

Hydraulic Systems: Ideal for use in hydraulic systems where high pressure and reliable fluid transportation are essential.
Fluid Transport: The black steel pipes are widely used for high-pressure fluid transfer in various industries, including construction, automotive, and manufacturing.
Automotive: Used in automotive hydraulic systems such as power steering, brake lines, and suspension systems.
Industrial Equipment: Commonly used in industrial machinery like presses, cranes, and other equipment requiring high-pressure fluid flow.
Construction Machinery: These pipes are perfect for use in construction equipment, such as excavators, loaders, and other heavy machinery, ensuring smooth operation and power transmission.
